LANKELEISI XC4000
Motor Power
1000W/70N·m
Motor Power
Battery
17.5Ah/840Wh
Battery
Up To Range
150KM
Up To Range
Top Speed
38KM/H
Top Speed
Tires
4.0"Fat Tires
Tires
Max load
200KG
Max load
LANKELEISI XC4000

LANKELEISI XC4000

Turn challenging rides into pure enjoyment.
€1.499,00 €1.599,00 Save €100,00
Color:Black Green
Accessories
  • PayPal
  • Klarna
  • Visa
  • Google Pay
  • Apple Pay
  • Mastercard
  • Maestro
  • Discover
  • JCB

Free Shipping

3 Year Warranty

14-Day Return

Motor Power
1000W/70N·m
Motor Power
Battery
17.5Ah/840Wh
Battery
Up To Range
150KM
Up To Range
Top Speed
38KM/H
Top Speed
Tires
4.0"Fat Tires
Tires
Max load
200KG
Max load
×
Desktop image
Mobile image

XC4000
Turn challenging rides into pure enjoyment.

Product Highlights

• 1000W High Speed Brushless Motor

The Lankeleisi XC4000 electric bicycle is equipped with rear 1000W high-speed brushless motor. It adopts inner star gear design enhances torque and improves energy efficiency conversion rate. While improving mileage, speed and climbing efficiency, it also reduces energy consumption and is quieter, with fast power output.

• 48V17.5Ah Removable Lithium Battery

The bike has a removable 48V 17.5Ah 18650 lithium battery, easy charge, lP54 waterproof, double protection, strong output and always stable. Its pure electric range can up to 50km, pedal assist range can reach 150km, providing sufficient power output for free riding.

• Fenders & Rear Rack

Pre-installed fenders will keep you protected on those ruggedroutes, in any weather, while an included rear rack means youcan carry all that you need wherever the road takes you.

• LCD Display

XC4000 device intelligent LCD instrument, brand new color interactive interface, LCD display, integrated gear switch, bicycle data viewing, power output setting, clear at a glance, IP64 waterproof and dustproof quality reliable.

• Shimano 7 speed transmission

Optional imported Shimano 7-speed transmission system, customized alumi num alloy crank 52T sprocket, the first classic combination of the first seven levels, sis positioning, durability and 7-speed greatly improve the riding pleasure.

• Note

In the EU, riders are responsible for complying with the 25 km/h speed limit on public roads. Our e-bikes are factory-set to this limit by default. The restriction can be removed for use on private land.

Range Test in Practice

Achievable range on mixed urban terrain

Full Throttle
*It can be used in private venues (this is for personalized expansion).
Preset max-25 km/h
0 km
After unlocked max-38km/h
0 km
Pedal Assist
PAS1:(ECO)
0 km
PAS2:(Normal)
0 km
PAS3:(Sport)
0 km
PAS4:(Turbo)
0 km
PAS5:(Turbo+)
0 km
Results obtained with a 60kg rider, on flat terrain at 27°C. Range in your riding may be longer or shorter, depending on factors such as terrain, load, wind, temperature and tire pressure etc.
Specification & Geometry
Standard
Geometry
Spec
Mechanical
180cm
180cm Height

Slide the scale for your bike inseam measurement

LANKELEISI XC4000 (Standard)

You will be able to pedal and stand over the frame comfortably.

LANKELEISI XC4000 (Standard)

You may experience discomfort on extended riding periods.

Person Bike
SIZE(mm) One Size
Applicable Height 5'5"(165cm)~6'3"(190cm)
A-Max Saddle Height 1050
B-Min Saddle Height 900
C-Seat tube length 457
D-Effective top tube 610
E-Head tube 150
F-Bar Height 1100
G-Chainstay 485
H-Wheelbase 1150
I-Standover Height 770
J-Seat tube angle 74°
K-Steering angle 71°
L-E-bike length 1880
*Specifcations are subject to change without notice.In case ofunexpected supply-sideimpacts, we will offer components ofequivalent or better capabilities.
table image
SIZE(mm) One Size
Applicable Height 5'5"(165cm)~6'3"(190cm)
A-Max Saddle Height 1050
B-Min Saddle Height 900
C-Seat tube length 457
D-Effective top tube 610
E-Head tube 150
F-Bar Height 1100
G-Chainstay 485
H-Wheelbase 1150
I-Standover Height 770
J-Seat tube angle 74°
K-Steering angle 71°
L-E-bike length 1880
*Specifcations are subject to change without notice.In case ofunexpected supply-sideimpacts, we will offer components ofequivalent or better capabilities.
Battery 48V17.5A 18650 lithium battery Charger 48V3A fast charger
Charging time 6-7 hours Battery life 1000 charges
Motor 1000W brushless motor Speed Class Up to 38 KM/H on Level 5 PAS
Net Weight 28kg (including battery) Max Load 200KG
Range 120KM Torque 70 N·m
Battery 48V17.5A 18650 lithium battery
Charger 48V3A fast charger
Charging time 6-7 hours
Battery life 1000 charges
Motor 1000W brushless motor
Speed Class Up to 38 KM/H on Level 5 PAS
Net Weight 28kg (including battery)
Max Load 200KG
Range 120KM
Torque 70 N·m
Tire 26 * 4.0" CHAOYANG Fat Tire Display Smart LCD instrument
Brake ZOOM Power-off hydraulic disc brake Chain KMC Stainless Chain
Crank 52T Aluminum alloy crankset Gearing Shimano 7-Speed
Derailleur Shimano TY300 rear derailleur Front fork Oil spring shock absorber front fork
Frame Material 6061 Aluminum alloy Handlebar 31.8*730mm aluminum alloy
Rims Aluminum Alloy Kickstand 6061 Aluminum Kickstand
Saddle Quality sport seat Sensor Cadence Sensor
Tire 26 * 4.0" CHAOYANG Fat Tire
Display Smart LCD instrument
Brake ZOOM Power-off hydraulic disc brake
Chain KMC Stainless Chain
Crank 52T Aluminum alloy crankset
Gearing Shimano 7-Speed
Derailleur Shimano TY300 rear derailleur
Front fork Oil spring shock absorber front fork
Frame Material 6061 Aluminum alloy
Handlebar 31.8*730mm aluminum alloy
Rims Aluminum Alloy
Kickstand 6061 Aluminum Kickstand
Saddle Quality sport seat
Sensor Cadence Sensor
