Dukawey DM530PLUS
Motor Power
52V1000W
Motor Power
Battery
20Ah/1040Wh
Battery
Up To Range
150KM
Up To Range
Top Speed
52KM/H
Top Speed
Tires
4.0"Fat Tires
Tires
Max load
200KG
Max load
Dukawey DM530PLUS

Dukawey DM530PLUS

It also drives smoothly on mixed roads.
€1.699,00 €1.899,00 Save €200,00
Color:Black Gray
Accessories
  • PayPal
  • Klarna
  • Visa
  • Google Pay
  • Apple Pay
  • Mastercard
  • Maestro
  • Discover
  • JCB

Free Shipping

3 Year Warranty

14-Day Return

Motor Power
52V1000W
Motor Power
Battery
20Ah/1040Wh
Battery
Up To Range
150KM
Up To Range
Top Speed
52KM/H
Top Speed
Tires
4.0"Fat Tires
Tires
Max load
200KG
Max load
×
Desktop image
Mobile image

DM530PLUS
It also drives smoothly on mixed roads.

Product Highlights

• 52V20Ah Samsung High-Capacity 21700 Lithium Battery

52V20ah power 21700 lithium battery pack, powerful output, always stable. Pure electric up to 70KM, assisted riding up to 150kM, providing sufficient power output for cycling and free riding.

• 52V1000W High Speed Brushless Motor

The Dukawey DM530Plus electric mountain bike has 52V1000W rear high speed brushless motor. strong power, top speed can reach 52km/h and climb angle can reach 40°. The motor adopts a star gear design, which can effectively amplify torque and increase output power, giving the bicycle stronger speed and climbing performance.

• Hydraulic disk brake

It adopts front and rear power-off oil disc brake system, 180mm brake disc, which has fast heat dissipation and can brake efficiently and smoothly even in emergency braking.

• Step Through Frame Design

Step through design, easy to ride, suitable for city use. and the frame adopts 6061 aluminum alloy material with T4T6 heat treatment, has higher strength, corrosion resistance and rust resistance, and ensures the support strength of each part and safe riding.

• Color Smart LCD meter

DM530 Plus device intelligent LCD instrument, brand new interactive interface, LCD display, integrated gear switch, bicycle data view, power output setting, clear at a glance, ip64 waterproof and dustproof, quality is reliable.

• Note

In the EU, riders are responsible for complying with the 25 km/h speed limit on public roads. Our e-bikes are factory-set to this limit by default. The restriction can be removed for use on private land.

Range Test in Practice

Achievable range on mixed urban terrain

Full Throttle
*It can be used in private venues (this is for personalized expansion).
Preset max-25 km/h
0 km
After unlocked max-52 km/h
0 km
Pedal Assist
PAS1:(ECO)
0 km
PAS2:(Normal)
0 km
PAS3:(Sport)
0 km
PAS4:(Turbo)
0 km
PAS5:(Turbo+)
0 km
Results obtained with a 60kg rider, on flat terrain at 27°C. Range in your riding may be longer or shorter, depending on factors such as terrain, load, wind, temperature and tire pressure etc.
Specification & Geometry
Standard
Geometry
Spec
Mechanical
180cm
180cm Height

Slide the scale for your bike inseam measurement

Dukawey DM530PLUS (Standard)

You will be able to pedal and stand over the frame comfortably.

Dukawey DM530PLUS (Standard)

You may experience discomfort on extended riding periods.

Person Bike
SIZE(mm) One Size
Applicable Height 5'3"(160cm)~6'3"(190cm)
A-Max Saddle Height 1050
B-Min Saddle Height 900
C-Seat tube length 457
D-Effective top tube 620
E-Head tube 150
F-Bar Height 1150~1230
G-Chainstay 480
H-Wheelbase 1155
I-Standover Height 620
J-Seat tube angle 72°
K-Steering angle 69°
L-E-bike length 1900
*Specifcations are subject to change without notice.In case ofunexpected supply-sideimpacts, we will offer components ofequivalent or better capabilities.
table image
SIZE(mm) One Size
Applicable Height 5'3"(160cm)~6'3"(190cm)
A-Max Saddle Height 1050
B-Min Saddle Height 900
C-Seat tube length 457
D-Effective top tube 620
E-Head tube 150
F-Bar Height 1150~1230
G-Chainstay 480
H-Wheelbase 1155
I-Standover Height 620
J-Seat tube angle 72°
K-Steering angle 69°
L-E-bike length 1900
*Specifcations are subject to change without notice.In case ofunexpected supply-sideimpacts, we will offer components ofequivalent or better capabilities.
Battery 52V20A Samsung battery Charger 52V3A fast charger
Charging time 6-7 hours Battery life 1000 charges
Motor 52V1000W brushless Motor Speed Class Up to 52 KM/H on Level 5 PAS
Net Weight 36KG (including battery) Max Load 200KG
Range 150KM Torque 89 N.m
Battery 52V20A Samsung battery
Charger 52V3A fast charger
Charging time 6-7 hours
Battery life 1000 charges
Motor 52V1000W brushless Motor
Speed Class Up to 52 KM/H on Level 5 PAS
Net Weight 36KG (including battery)
Max Load 200KG
Range 150KM
Torque 89 N.m
Tire 26 x 4.0" rubber fat tires Display Color LCD display
Brake Hydraulic disc brakes & 180MM discs Chain KMC Stainless Chain
Crank 46T Aluminum alloy crankset Gearing Shimano 7-Speed
Derailleur Shimano M310-7 speed Front fork Oil spring front fork
Frame Material 6061 Aluminum alloy Handlebar 31.8mm aluminum alloy
Rims Aluminum Alloy Kickstand 6061 Aluminum Kickstand
Saddle Quality sport seat Headlights LED highlight headlights & LED taillights
Tire 26 x 4.0" rubber fat tires
Display Color LCD display
Brake Hydraulic disc brakes & 180MM discs
Chain KMC Stainless Chain
Crank 46T Aluminum alloy crankset
Gearing Shimano 7-Speed
Derailleur Shimano M310-7 speed
Front fork Oil spring front fork
Frame Material 6061 Aluminum alloy
Handlebar 31.8mm aluminum alloy
Rims Aluminum Alloy
Kickstand 6061 Aluminum Kickstand
Saddle Quality sport seat
Headlights LED highlight headlights & LED taillights
